Mobile Filtration System

Mobile Filtration System for high viscosity applications is a compact, self contained filtration  system equipped with high efficiency, high capacity elements capable of removing particulate contamination  and/or water quickly, conveniently and economically. It is perfect for cleaning up existing systems as well as  prefiltering and transferring fluids. Remember, new fluid does not mean clean fluid! Most new fluids have  contamination levels significantly higher than is recommended for most hydraulic systems.

Features and Benefits ■ Ability to filter fluids having a viscosity up to  15,000 SUS

■ Flow rates up to 3 gpm

■ 115 V AC single phase 1 1/2 HP motor  ■ Dual filtration unit, available to remove both water  and particulate contamination or for staged particulate  contamination removal

■ Modular base eliminates hoses between components  and minimizes leakage

■ Base-ported filter provides easy element service from  the top cap  ■ Ten-foot hose and extension tubes included  (13' total length)

■ Drip pan catches oil before it falls to the ground  ■ 27-inch housing is standard

■ Integrated lifting eye option  The Schroeder Mobile Filtration System for high viscosity applications is a compact, self contained filtration  system equipped with high efficiency, high capacity elements capable of removing particulate contamination  and/or water quickly, conveniently and economically. It is perfect for cleaning up existing systems as well as  prefiltering and transferring fluids. Remember, new fluid does not mean clean fluid! Most new fluids have contamination levels significantly higher than is recommended for most hydraulic systems.

Specifications ■ Supplementing continuous filtration by system filters

■ Cleaning up a hydraulic system following component  replacement ■ Filtering new fluid before it is put into service

■ Transferring fluid from storage tanks and drums to  system reservoirs
