white water filtration in paper industry

self-cleaning filter is researched and developed based on auto self clean filter. It's suitable for harsh conditions where there are various types juice of impurities include white water ，sea water ，cooling water ，sugar sauce ect.The design is multi-functional and structured. The cleaning component uses sucking and back wash (assinte the high pump offer clean water )  It's able to clean impurities adsorbed on the filter element surface very effectively. When the filter pressure difference between the inside and outside of the filter mesh reaches the default values or the regular cleaning. Products Description Self-cleaning backflushing clarified filter, also for highly viscous media and high temperatures.

Fully automatic backflushing filters are primarily used for the filtration of white water , Raw water   shower water or River water and work almost wear-free. Due to its power  backflushing system, this self-cleaning filter can also be used for highly viscous media and in high temperature areas. The cleaning process is possible without interruption of filtration. To remove impurities from clarified cane juice such as bagacillo, cellular materials, and residual flocs, to replace current  wedge screen  screen or cloth screening methods. The advantages of these new backflush technologies are: - Virtually no power consumption (except for automatic valves) - Self cleaning system - Virtually no recycle of  water  with bagacillo – typically 0.001% - No heat loss – totally enclosed insulated system - Virtually Maintenance free

The waste water enter into the filter, In filter process, the fine screen surface gradually accumulates the impurities from the water, then form the filter impurity layer. Because the impuritiesaccumulate in inside of the fine screen, then forming a pressure difference inside and outside of the fine screenWhen the differential pressure system reaches the preset value, the system of water supply is not interrupted, open backwash valve or drain valve, the waste water outlet from the drain valve. While the pressure go down in the hydraulic motor chamber and dirt collector, then the suction nozzle of suction assembly begin suction process: there is a very strong backwash water flow to the outside, the suction nozzle produce a suction power plus the flow power through the hydraulic motor. Because the hydraulic piston pressure go down, lead the dirt collector rotate around the axis of rotation to move, so perfectly clean the inner surface of fine screen. This type of filter is simultaneously provided with a timing controller, which can regular blowdown in certain time.

Applicable industries: Water treatment, steel, pulp and paper, mining, petro-chemical, machining, municipal, irrigation etc.

Typical applicable liquids: Groundwater, seawater, lake, reservoir water, pond water, cooling water circulation, frozen water, high and low voltage gush to drench water, squirt water, heat water, seal water, bearing cooling water, oil wells note water, process of circulating water, machining coolant, cleaning agents, cleaning water, etc.

Filtration function: Remove large particles, purify liquids, protect critical equipment.

Filtration type: Back-flushing filter, automatic continuously online filtration
